TC-30/50C Taylor Dunn

Description

The Tiger Cub tow tractor has been completely redesigned to provide a compact, highly maneuverable solution for towing requirements demanding drawbar pull of 3,000-5,000 lbs.

Model

TC-30/50C

Type

Combustion

Speed

13 mph (21 km/h)

Load Capacity

N/A

Tow Capacity

DBP: 3,000-5,000 lbs

People

1

Description

The Tiger Cub is available with LPG or gasoline engines. Unitized fully welded steel frame, all-wheel suspension, extra low step height, and traction style tires result in a tow tractor that will withstand harsh environments yet maintain operator comfort. WebRep currentVote noRating noWeight

Options

– Cab

– Heater & defroster

– Turn signals

– Fire extinguisher

– Custom paint color

– Overhead guard

– Beacon light

– Back-up alarm

– Seat belt

– Various hitches

– High stall torque converter

– Shift inhibitor (full range shifter)

– Shift inhibitor (FNR shifter)

– 13 gallon tank

– LPG tank

– Foam filled tires





WebRepcurrentVotenoRatingnoWeight

WebRepcurrentVotenoRatingnoWeight

Performance

Speed

13 mph (21 km/h)

Load Capacity

N/A

Tow Capacity

DBP: 3,000-5,000 lbs

Passengers

1

Dimensions

Weight

4,800 lbs (2177 kg) – 6,150 lbs (2789 kg)

Length

96″ (243.8cm)

Width

44.25″ (112.4cm)

Height

Less Cab: 64″ (162.6cm) With Cab: 88″ (221cm)

Hitch Height

13″ (33.0cm)

Outside Turn Radius

120″ (304.8cm)

Wheel Base

49.25″ (125cm)

Deck

Width: N/A Length: N/A Height: N/A
