B-210 GT Taylor Dunn

Description

The B-210 is designed to provide a cost effective solution for your utility applications. Vehicle performance meets or exceeds any comparable gasoline powered vehicles while providing lower maintenance and operating costs.

Model

B-210 GT

Type

Electric

Speed

11 mph (17.7 km/h)

Range

24 miles (38 km)

Load Capacity

2,400 lbs. (1,088.6 kg.)

Tow Capacity

8,400 lbs. (3818 kg)

People

2

Description

With growing concerns related to noise and air pollution, the B-210 provides an ideal solution without compromising performance. Its unique design features allow the vehicle to be reconfigured to personnel carrier, burden carrier or tow vehicle in the field to meet your changing needs. The B-210 is equipped with a 36 volt GT electric drive system that utilizes an automotive differential that provides years of reliable service.  Equipped standard with on-board automatic charger, battery discharge indicator, dual headlights, taillights, and hydraulic brakes, makes the B-210 the best value in its class of vehicles. The B-210 with steel cab and doors, stake sides, cargo box, tool box, 4- or 6-passenger designs can be configured to meet your specific needs.

Options

Charger

– Portable 25 amp charger
– Portable 40 amp charger 110v/220v
– Built-in 110v/220v 50 Hz

Accessories

– Strobe light, amber – on pole, or top of cab
– Reverse buzzer
– Directional signals
– Hour meter
– Seat interlock switch

Cab

– Steel cab with safety glass window
– Metal doors with sliding safety glass window
– Windshield wiper for cab
– Mirrors: left, right and rear

Deck

– Stake sides, removable end gate, 14” high
– Steel sides and end gates, fold down
– Diamond plate deck
– Steel panel cargo box

Battery Compartment

– 244 amp-hour batteries

Hitches

– Hitch automatic coupling, trailer
– Hitch pintle trailer
– Hitch 1-7/8” ball and bracket

Brakes

– Front wheel hydraulic

Top Frames

– Fiberglass or surrey top cover with tubular frame

Frame

– Fixed seating 4-6 passengers

Color

– Special paint color
– Undercoating

Performance

Speed

11 mph (17.7 km/h)

Range

24 miles (38 km)

Load Capacity

2,400 lbs. (1,088.6 kg.)

Tow Capacity

8,400 lbs. (3818 kg)

Passengers

2

Dimensions

Weight

1,405 lbs. (636 kg.)

Length

120.75″ (306cm)

Width

45″ (114.3cm)

Height

Less Cab: 48″ (122.0cm) With Cab: 74″ (188.0cm)

Hitch Height

11″ (27.9cm)

Outside Turn Radius

125″ (312.0cm)

Wheel Base

54.5″ (138.4cm)

Deck

Width: 43″ (109.22cm) Length: 75″ (190.5cm) Height: 26.12″ (66.3cm)
