660SJC JLG

Details

  • For your toughest jobs and terrains, the 600 Crawler Series provides the mobility you need
  • Single drive / steer joystick for one-handed operation
  • Zero turning radius to get around the jobsite easier

Power Source

Auxiliary Power

12 Volts DC

Capacity Fuel Tank

40 gal. / 151.42 L

Engine Type Diesel

DEUTZ TD 2.9L Tier 4 Final 67 hp

Performance

Axle Oscillation

0 in. / 0 mm

Drive Speed Wd

1.60 mph / 2.57 km/h

Gradeability Wd

55 %

Platform Capacity Unrestricted

500 lb / 226.80 kg

Swing

360 Degrees

Swing Type

Continuous

Turning Radius Outside

0 in. / 0 mm

Jib Range Of Articulation

132 Degrees

Dimensional Data

Ground Clearance

1 ft 3 in. / 0.38 m

Machine Height

8 ft 5 in. / 2.57 m

Machine Length

33 ft 6 in. / 10.21 m

Machine Width

8 ft 2 in. / 2.49 m

Platform Dimension A

3 ft / 0.91 m

Platform Dimension B

8 ft / 2.44 m

Platform Height

66 ft 8 in. / 20.32 m

Tailswing

3 ft 8 in. / 1.12 m

Track Width

1 ft 8 in. / 0.51 m

Reach Specifications

Horizontal Jib Rotation

0 Degrees

Horizontal Outreach

56 ft 9 in. / 17.3 m

Platform Height

66 ft 8 in. / 20.32 m

General

Capacity Hydraulic Reservoir

32 gal. / 121.13 L

Machine Weight

27100 lb / 12292.35 kg
