T500J JLG

Details

  • Gasoline engine or 24V DC electric power
  • Standard air and water lines to platform
  • Accessory Mounting Tray accommodates your generator, air compressor or pressure washer

Power Source

Batteries

4 x 6V 220 amp-hr

General

Capacity Hydraulic Reservoir

6 gal. / 22.71 L

Machine Weight

4800 lb / 2177.24 kg

Performance

Frame Leveling

11 Degrees

Leveling Capability

11 Degrees

Outriggers Or Stabilizers

Yes

Platform Capacity

500 lb / 226.80 kg

Swing

410 Degrees

Swing Type

Non-Continuous

Towing Speed Rating

65 mph / 104.61 km/h

Jib Range Of Articulation

130 Degrees

Dimensional Data

Ground Clearance

1 ft 3 in. / 0.38 m

Ground Entry Height

1 ft 3 in. / 0.38 m

Machine Height

7 ft 5 in. / 2.26 m

Machine Length

27 ft 4 in. / 8.33 m

Machine Width

5 ft 7 in. / 1.7 m

Outrigger Footprint Length

12 ft 4 in. / 3.76 m

Outrigger Footprint Width

12 ft 8 in. / 3.86 m

Platform Dimension A

2 ft 6 in. / 0.76 m

Platform Dimension B

4 ft / 1.22 m

Platform Height

50 ft / 15.24 m

Tire Size

225/75 R14 Pnuematic

Reach Specifications

Horizontal Outreach

30 ft / 9.14 m

Platform Height

50 ft / 15.24 m

Up And Over Height

18 ft / 5.49 m
