Details
  • Superior performance on or off slab
  • Rugged terrain tires take you anywhere you want to go
  • With optional hydraulic leveling jacks, uneven terrain is no problem
  • Double the duty cycle of other scissor lifts so you can stay on the job longer

Power Source

Batteries

8 x 6V, 370 amp-hour

Charger

21 Amp Automatic SCR

General

Brakes

Spring Applied Hyd. Released Discs

Capacity Hydraulic Reservoir

9 gal. / 32.18 L

Hydraulic Pump

Single Section Gear Pump

Machine Weight

9760 lb / 4427.06 kg

Performance

Drive Speed Platform Elevated

0.40 mph / 0.64 km/h

Drive Speed Platform Lowered

3 mph / 4.83 km/h

Gradeability Wd

35 %

Lift Time

38 sec.

Lower Time

42 sec.

Maximum Drive Height

33 ft / 10.06 m

Maximum Lift Height

33 ft / 10.06 m

Platform Capacity

1000 lb / 453.59 kg

Platform Capacity Extension

250 lb / 113.40 kg

Turning Radius Outside

15 ft 6 in. / 4.72 m

Dimensional Data

Ground Clearance

8 in. / 0.2 m

Machine Height

9 ft / 2.74 m

Machine Height Rails Folded

6 ft 5 in. / 1.96 m

Machine Length

10 ft 4 in. / 3.15 m

Machine Width

5 ft 9 in. / 1.75 m

Platform Dimension A

9 ft 7 in. / 2.92 m

Platform Dimension B

5 ft 5 in. / 1.65 m

Platform Extension Length

3 ft / 0.91 m

Platform Height

33 ft / 10.06 m

Platform Height Lowered

5 ft 7 in. / 1.69 m

Platform Railing Height

3 ft 8 in. / 1.1 m

Tire Size

240/55 x 17.5 Non-Marking

Wheelbase

7 ft 7 in. / 2.3 m

Reach Specifications

Platform Height

33 ft / 10.06 m

Working Height

39 ft / 11.89 m
