Details
  • Active pothole protection provides increased ground clearance
  • Fewer parts and an improved battery charger for greater serviceability
  • All-steel platform and component doors and thicker rubber tires for added durability

Power Source

Batteries

4 x 6V 220 amp-hour

Charger

27 amp Universal Algorithm

General

Brakes

Multi-Disc Friction

Capacity Hydraulic Reservoir

5 gal. / 17.03 L

Hydraulic Pump

Fixed Displacement Gear

Machine Weight

2630 lb / 1192.95 kg

Performance

Drive Speed Platform Elevated

0.50 mph / 0.80 km/h

Drive Speed Platform Lowered

2 mph / 3.22 km/h

Drive System

Hydraulic Front Wheel

Gradeability

25 %

Lift Time

25 sec.

Lower Time

26 sec.

Maximum Drive Height

19 ft / 5.79 m

Platform Capacity Extension

250 lb / 113.40 kg

Platform Capacity Unrestricted

550 lb / 249.48 kg

Turning Radius Inside

0 in. / 0 mm

Turning Radius Outside

5 ft 6 in. / 1.68 m

Dimensional Data

Ground Clearance

3 in. / 0.07 m

Machine Height

6 ft 11 in. / 2.1 m

Machine Length

5 ft 9 in. / 1.74 m

Machine Width

2 ft 8 in. / 0.81 m

Platform Dimension A

2 ft 2 in. / 0.65 m

Platform Dimension B

5 ft 3 in. / 1.59 m

Platform Extension Length

3 ft / 0.91 m

Platform Height

19 ft / 5.79 m

Platform Height Lowered

3 ft 3 in. / 0.98 m

Platform Railing Height

3 ft 4 in. / 1.01 m

Tire Size

12 x 4 in

Wheelbase

4 ft 5 in. / 1.35 m

Reach Specifications

Platform Height

19 ft / 5.79 m

Working Height

25 ft / 7.62 m
