B-248 48V GT Taylor Dunn

Description

The B-248 series product line of electric personnel and burden carriers offers the ultimate versatility in load capacity, vehicle configuration and vehicle performance.

Model

B-248 48V GT

Type

Electric

Speed

16 mph (25.7 km/h)

Range

24 miles (38 km)

Load Capacity

3,000 lbs. (1,360 kg)

Tow Capacity

12,500 lbs. (5,682 kg)

People

2

Description

The B-248’s unique modular vehicle design allows the B-248 to be configured to provide precise solutions to your needs. The B-248 series, equipped with GT electric drive train, provides years of reliability with low operating costs. The B-248 can be configured to carry up to 4,000 pounds of load, pull 17,500 pounds, or carry up to 10 people. Equipped with an automotive differential matched to a 48 volt drive train, the B-248 is one of the best values for your utility applications.

Options

Charger

– Portable 25 amp charger or 40 amp charger

Accessories

– Strobe light, amber – on pole, or top of cab

– Dual headlights, directional signals

– Hour meter, automatic park brake

Deck

– 1,000 lb. capacity, electric hydraulic dump body

– Stake sides, removable end gate, 14″ high

– 96 inch bed length (extended wheel base)

– Welding tank cutouts

– Steel sides and end gates, fold down

– Steel panel cargo box

Battery Compartment

– 244 amp-hour batteries

– Lift out/roll out battery box

Hitches

– Automatic coupling, trailer

– Pintle trailer

– Ball hitch and bracket

Cab

– Steel cab with doors

– Fiberglass cab

Top Covers

– Fiberglass or surrey top cover with tubular frame

Frame

– Foldaway seat for 2 additional passengers

– Permanent seating 4-6 passengers

– Smooth skin

Color

– Green, White, Yellow, or special paint color

– Undercoating

Brakes

– Front hydraulic disc brakes

Performance

Speed

16 mph (25.7 km/h)

Range

24 miles (38 km)

Load Capacity

3,000 lbs. (1,360 kg)

Tow Capacity

12,500 lbs. (5,682 kg)

Passengers

2

Dimensions

Weight

1,550 lbs (702 kg.)

Length

121″ (307.3cm)

Width

45″ (114.2cm)

Height

Less Cab: 45″ (114.2cm) With Cab: 69″ (172.2cm)

Hitch Height

12.5″ (31.8cm)

Outside Turn Radius

138″ (350.4cm)

Wheel Base

55″ (139.8cm)

Deck

Width: 41.25″ Length: 75.25″ Height: 25″ (63.5cm)
